Architecturally inspired systems for superior style and performance

Commercial Double-Hung Window

Commercial Series | Series 453

Commercial Double-Hung Window

Commercial Double-Hung Window

For beauty, choice and flexibility across large installations, check out the Elevate™ Series 453 Commercial Double-Hung Window.

  • Vertical sliding, double-hung sashes are inlaid directly into commercial framing to suit larger window spans.
  • This window can even be fitted with concealed flyscreens to give your building a sleek, modern appearance.
  • Tested to a high water resistance of 200Pa, the clever bi-fold design allows sashes to bypass each other for easy cleaning from inside the building. Fixed lowlights can also be glazed from the inside in elevated installations through a simple customisation at assembly.
  • If security is a concern, you can breathe easy with the added protection of our heavy-duty, key lockable catch with die-cast keeper.
  • These windows are also suitable for use in cavity brick and brick veneer construction. So convenient!
*Maximum Frame Height and Panel Widths indicated are interdependent and subject to individual site conditions.
Maximum Frame Height* 1050mm
Maximum Panel Width* 1155mm
Maximum Glass Thickness ≤ 7.50mm
SHGC Range 0.29 - 0.64
Uw Range 4.9 - 6.5

Key Features / Performance Characteristics

  • Vertical sliding double-hung sashes inlaid directly into commercial framing.
  • Flyscreens tuck into dedicated recess in the jamb inlay adapter, supported with concealed nylon clips on this commerical double hung window.
  • This commercial double hung window complies with AS2047. It has high water resistance 200Pa.
  • These bi-fold window sashes will bypass each other to allow cleaning of all glass from inside the building.
  • Custom heavy duty key lockable catch with die-cast keeper.
  • Fixed lowlights can be glazed from the inside in elevated situations by reversing the removable glazing beads and fitting custom captive wedge to the outside.
  • Nailing fin frame makes the product suitable for cavity brick and brick veneer construction.
